- High power light output.
- Excellent light spread.
- Slimline design - 12mm deep.
- Available in 12V or 24V.
- Light stays on for 30 seconds after the PIR is activated.
- Waterproof, non-PIR option also available.
- Some variants are made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R10.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | INTEGRAL SWITCH | PIR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| IL10PIR | Splashproof LED Strip Light, 12V - with Integral PIR | 12 | 0.25A @ 12V | 390 | None | White | Clear | No | Yes | N/A | 0.074 | 21(H) X 237(L) X 12(D) |
| IL10DPIR | Splashproof LED Strip Light, 24V - with Integral PIR | 24 | 0.2A @ 24V | 390 | None | White | Clear | No | Yes | N/A | 0.074 | 21(H) X 237(L) X 12(D) |
| IL10DPIRS | Splashproof LED Strip Light, 24V - with Integral PIR with Superseal Connector | 24 | 0.2A @ 24V | 430 | Superseal | White | Clear | No | Yes | N/A | 0.078 | 21(H) X 237(L) X 12(D) |
| IL10PIRS | Splashproof LED Strip Light, 12V - with Integral PIR with Superseal Connector | 12 | 0.25A @ 12V | 430 | Superseal | White | Clear | No | Yes | N/A | 0.078 | 21(H) X 237(L) X 12(D) |
Download Product Information
- IL10PIR Product Spec Sheet Download
- IL10DPIR Product Spec Sheet Download
- IL10DPIRS Product Spec Sheet Download
- IL10PIRS Product Spec Sheet Download
- IL10PIR Technical Drawing Download
- IL10DPIR Technical Drawing Download
- IL10DPIRS Technical Drawing Download
- IL10PIRS Technical Drawing Download
To download product materials, please login or register for an account.
