- Robust, fully potted resin construction in aluminium housing.
- Intense light output.
- Incredible 120 ° light spread.
- Only 8mm deep by 16mm wide.
- Cost effective.
- ILP300 white version is available in 12V and 24V. Colour versions available in 24V.
- Different colour options and lengths available across ILP Series.
- Some variants are made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R10.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | LIGHT COLOUR TEMPERATURE (°KELVINS) | INTEGRAL SWITCH | PIR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ILP300 | High Power Waterproof LED Strip Light - 300mm - White, 12V | IP65 | 12 | 0.34A @ 12V | 300 | None | White | Clear | 6000 | No | No | N/A | 0.086 | 8(H) X 300(L) X 16(D) |
| ILP300/08 | High Power Waterproof LED Strip Light - 300mm - White, 12V, 800mm Cable | IP65 | 12 | 0.34A @ 12V | 800 | None | White | Clear | 6000 | No | No | N/A | 0.1 | 8(H) X 300(L) X 16(D) |
| ILP300D | High Power Waterproof LED Strip Light - 300mm - White, 24V | IP65 | 24 | 0.18A @24V | 300 | None | White | Clear | 6000 | No | No | N/A | 0.086 | 8(H) X 300(L) X 16(D) |
| ILP300D/4M | High Power Waterproof LED Strip Light - 300mm - White, 24V, 4m Cable | IP65 | 24 | 0.18A @24V | 4000 | None | White | Clear | 6000 | No | No | N/A | 0.22 | 8(H) X 300(L) X 16(D) |
| ILP300D/8M | High Power Waterproof LED Strip Light - 300mm - White, 24V, 8m Cable | IP65 | 24 | 0.18A @24V | 8000 | None | White | Clear | 6000 | No | No | N/A | 0.36 | 8(H) X 300(L) X 16(D) |
| ILP300S | High Power Waterproof LED Strip Light - 300mm - White, 12V, Switch | IP65 | 12 | 0.34A @ 12V | 300 | None | White | Clear | 6000 | No | No | N/A | 0.086 | 8(H) X 300(L) X 16(D) |
Download Product Information
- ILP300 Product Spec Sheet Download
- ILP300/08 Product Spec Sheet Download
- ILP300D Product Spec Sheet Download
- ILP300D/4M Product Spec Sheet Download
- ILP300D/8M Product Spec Sheet Download
- ILP300S Product Spec Sheet Download
- ILP300 Technical Drawing Download
- ILP300/08 Technical Drawing Download
- ILP300D Technical Drawing Download
- ILP300D/4M Technical Drawing Download
- ILP300D/8M Technical Drawing Download
- ILP300S Technical Drawing Download
To download product materials, please login or register for an account.
