- Slimline design.
- Surface mount.
- ILV600 is available in 12V and 24V.
- Other voltage and switching options available in other lengths of the ILV Series.
- Some variants made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R10.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | LIGHT COLOUR TEMPERATURE (°KELVINS) | INTEGRAL SWITCH | PIR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ILV600 | High Power LED Strip Light - 662mm, 12V | IP20 | 12 | 0.685A @ 12V | 1000 | None | White | Clear | 6000 | No | No | N/A | 0.16 | 9(H) X 660(L) X 25(D) |
| ILV600/3M | High Power LED Strip Light - 662mm, 12V, 3m Cable | IP20 | 12 | 0.685A @ 12V | 3000 | None | White | Clear | 6000 | No | No | N/A | 9(H) X 660(L) X 25(D) | |
| ILV600D | High Power LED Strip Light - 662mm, 24V | IP20 | 24 | 0.37A @ 24V | 1000 | None | White | Clear | 6000 | No | No | N/A | 0.16 | 9(H) X 660(L) X 25(D) |
| ILV600S | High Power LED Strip Light - 662mm, 12V with Superseal Connector | IP20 | 12 | 0.685A @ 12V | 1040 | Superseal | White | Clear | 6000 | No | No | N/A | 0.164 | 9(H) X 660(L) X 25(D) |
Download Product Information
- ILV600 Product Spec Sheet Download
- ILV600/3M Product Spec Sheet Download
- ILV600D Product Spec Sheet Download
- ILV600S Product Spec Sheet Download
- ILV600 Technical Drawing Download
- ILV600/3M Technical Drawing Download
- ILV600D Technical Drawing Download
- ILV600S Technical Drawing Download
To download product materials, please login or register for an account.
