- Totally surface mount design.
- Suitable for rectangular or square number plates.
- Sealed unit.
- Dual voltage.
- Some variants are made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R4, R10.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| NP100 | Surface Mount LED Number Plate Light | IP67 | 12/24 | 0.08A @ 12V, 0.04A @ 24V | 250 | None | White | Clear | N/A | 0.037 | 41(H) X 72(L) X 50(D) |
| NP100/1.4M | Surface Mount LED Number Plate Light, 1.4m Cable | IP67 | 10-30 | 0.08A @ 12V, 0.04A @ 24V | 1400 | None | White | Clear | N/A | 0.096 | 41(H) X 72(L) X 50(D) |
| NP100/3M | Surface Mount LED Number Plate Light, 3m Cable | IP67 | 12/24 | 0.08A @ 12V, 0.04A @ 24V | 3000 | None | White | Clear | N/A | 0.156 | 41(H) X 72(L) X 50(D) |
| NP100S | Surface Mount LED Number Plate Light with Superseal Connector | IP67 | 12/24 | 0.08A @ 12V, 0.04A @ 24V | 290 | Superseal | White | Clear | N/A | 0.043 | 42(H) X 72(L) X 50(D) |
| NP100SF | Surface Mount LED Number Plate Light with Female Superseal Connector | IP67 | 12/24 | 0.08A @ 12V, 0.04A @ 24V | 290 | Superseal | White | Clear | N/A | 0.062 | 41(H) X 72(L) X 50(D) |
Download Product Information
- NP100 Product Spec Sheet Download
- NP100/1.4M Product Spec Sheet Download
- NP100/3M Product Spec Sheet Download
- NP100S Product Spec Sheet Download
- NP100SF Product Spec Sheet Download
- NP100 Technical Drawing Download
- NP100/1.4M Technical Drawing Download
- NP100/3M Technical Drawing Download
- NP100S Technical Drawing Download
- NP100SF Technical Drawing Download
To download product materials, please login or register for an account.
