- Stop / tail / indicator functions.
- Unique homogeneous tail function giving identity.
- Dual voltage.
- No visible fixings.
- ADR-approved version available.
- Front position / indicator option available in the same series.
- Warranty: 3 Years
- Approvals: ECE R10, R4, R6, R7
The options available for this product are summarised below.
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|
| RL145STI3.4 | LED Rear Combination Lamp - Stop/Tail/Indicator | IP68 | 12/24 | Stop: 0.08A @ 12V, 0.04A @ 24V, Tail: 0.15A @ 12V, 0.075A @ 24V, Indicator: 0.175A @ 12V, 0.0875A @ 24V | 3400 | Red/Amber | Red/Amber | N/A | 0.313 | 102(H) X 108(L) X 38(D) |
