- Slimline surface mount design.
- Robust construction.
- Dual voltage.
- Red lens versions available.
- Low profile option available.
- Some variants are made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R7, R10.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| RL682C | Slimline Surface Mount LED 3rd Brake Light - Clear Lens | IP68 | 12/24 | 0.108A @ 12V, 0.108A @ 24V | 390 | None | Red | Clear | N/A | 0.073 | 20.5(H) X 237(L) X 22(D) |
| RL682C/7 | Slimline Surface Mount LED 3rd Brake Light - Clear Lens, 7m Cable | IP68 | 12/24 | 0.108A @ 12V, 0.108A @ 24V | 7000 | None | Red | Clear | N/A | 0.396 | 20.5(H) X 237(L) X 22(D) |
| RL682CS/7 | Slimline Surface Mount LED 3rd Brake Light - Clear Lens with Superseal Connector, 7m Cable | IP68 | 12/24 | 0.108A @ 12V, 0.108A @ 24V | 7040 | Superseal | Red | Clear | N/A | 0.411 | 20.5(H) X 237(L) X 22(D) |
Download Product Information
- RL682C Product Spec Sheet Download
- RL682C/7 Product Spec Sheet Download
- RL682CS/7 Product Spec Sheet Download
- RL682C Technical Drawing Download
- RL682C/7 Technical Drawing Download
- RL682CS/7 Technical Drawing Download
To download product materials, please login or register for an account.
