- Extremely compact.
- Approved for mounting vertically and horizontally.
- Dual voltage.
- Surface mounted.
- Fog and reverse options available in the same series.
- Some variants are made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R6, R7, R10.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| RL83STI | LED Rear Light - Stop / Tail / Indicator | IP68 | 12/24 | 0.191A @ 12V, 0.189A @ 24V | 380 | None | Red/Amber | Clear | N/A | 0.113 | 47(H) X 108(L) X 23(D) |
| RL83STI/0.5 | LED Rear Light - Stop / Tail / Indicator, 0.5m Cable | IP68 | 12/24 | 0.191A @ 12V, 0.189A @ 24V | 500 | None | Red/Amber | Clear | N/A | 0.121 | 47(H) X 108(L) X 23(D) |
| RL83STIR | LED Rear Light - Stop / Tail / Indicator with Delphi Connector | IP68 | 12/24 | 0.191A @ 12V, 0.189A @ 24V | 550 | Delphi | Red/Amber | Clear | N/A | 0.131 | 47(H) X 108(L) X 23(D) |
| RL83STIS | LED Rear Light - Stop / Tail / Indicator with Superseal Connector | IP68 | 12/24 | 0.191A @ 12V, 0.189A @ 24V | 540 | SuperSeal | Red/Amber | Clear | N/A | 0.134 | 47(H) X 108(L) X 23(D) |
Download Product Information
- RL83STI Product Spec Sheet Download
- RL83STI/0.5 Product Spec Sheet Download
- RL83STIR Product Spec Sheet Download
- RL83STIS Product Spec Sheet Download
- RL83STI Technical Drawing Download
- RL83STI/0.5 Technical Drawing Download
- RL83STIR Technical Drawing Download
- RL83STIS Technical Drawing Download
To download product materials, please login or register for an account.
