- Angel-eye DRL, position, indicator feature with light-guide technology.
- Integrated Deutsch connector.
- Projector technology with ultimate light spread.
- Warranty: 3 Years
- Approvals: ECE R6, R7, R10, R87, R112, SAE DOT.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| RL.G90.KI.M | 90mm LED Headlight with High Beam / Indicator / Position | IP69K | 8-33 | High Beam: 1.4A @ 13.5V, 0.7A @ 28V, Indicator: 0.6A @ 13.5V, 0.3A @ 28V, Position: 0.04A @ 13.5V, 0.04A @ 28V | N/A | Deutsch | White | Clear | 90 | 0.538 | 92(D) |
