- Robust flexible housing.
- Dual polarity for foolproof installation.
- Integrated reflector.
- Short stalk with side marker option also available.
- 2.2m cable.
- Warranty: 3 Years
- Approvals: ECE R7, R10.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SLM604L/22 | LED Outline Marker Light - Front / Rear with Reflector - Left Side | IP68 | 12/24 | 0.042A @ 12V, 0.042A @ 24V | 2200 | None | Red/White | Red/Clear | N/A | 0.309 | 180(H) X 161(L) X 37(D) |
| SLM604R/22 | LED Outline Marker Light - Front / Rear with Reflector - Right Side | IP68 | 12/24 | 0.042A @ 12V, 0.042A @ 24V | 2200 | None | Red/White | Red/Clear | N/A | 0.309 | 180(H) X 161(L) X 37(D) |
