- Integral side marker.
- Integrated reflector.
- Robust flexible housing.
- Dual polarity for foolproof installation.
- Available with Superseal Connectors.
- Long stalk option also available.
- Some variants are made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R3, R7, R10, R91.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SLM643L | 60° Short Stalk LED Outline Marker Light - Front / Rear with Side Marker and Reflector - Left Side | IP68 | 12/24 | 0.140A @ 12V, 0.140A @ 24V | 220 | None | Red/White/Amber | Red/Clear | N/A | 0.17 | 131(H) X 130(L) X 37(D) |
| SLM643LS | 60° Short Stalk LED Outline Marker Light - Front / Rear with Side Marker and Reflector - Left Side with Superseal Connector | IP68 | 12/24 | 0.140A @ 12V, 0.140A @ 24V | 270 | Superseal | Red/White/Amber | Red/Clear | N/A | 0.174 | 131(H) X 130(L) X 37(D) |
| SLM643LSF | 60° Short Stalk LED Outline Marker Light - Front / Rear with Side Marker and Reflector - Left Side with Female Superseal Connector | IP68 | 12/24 | 0.140A @ 12V, 0.140A @ 24V | 305 | Superseal | Red/White/Amber | Red/Clear | N/A | 0.174 | 131(H) X 180(L) X 37(D) |
| SLM643R | 60° Short Stalk LED Outline Marker Light - Front / Rear with Side Marker and Reflector - Right Side | IP68 | 12/24 | 0.140A @ 12V, 0.140A @ 24V | 220 | None | Red/White/Amber | Red/Clear | N/A | 0.17 | 131(H) X 130(L) X 37(D) |
| SLM643RS | 60° Short Stalk LED Outline Marker Light - Front / Rear with Side Marker and Reflector - Right Side with Superseal Connector | IP68 | 12/24 | 0.140A @ 12V, 0.140A @ 24V | 270 | Superseal | Red/White/Amber | Red/Clear | N/A | 0.174 | 131(H) X 130(L) X 37(D) |
| SLM643RSF | 60° Short Stalk LED Outline Marker Light - Front / Rear with Side Marker and Reflector - Right Side with Female Superseal Connector | IP68 | 12/24 | 0.140A @ 12V, 0.140A @ 24V | 305 | Superseal | Red/White/Amber | Red/Clear | N/A | 0.174 | 131(H) X 180(L) X 37(D) |
Download Product Information
- SLM643L Product Spec Sheet Download
- SLM643LS Product Spec Sheet Download
- SLM643LSF Product Spec Sheet Download
- SLM643R Product Spec Sheet Download
- SLM643RS Product Spec Sheet Download
- SLM643RSF Product Spec Sheet Download
- SLM643L Technical Drawing Download
- SLM643LS Technical Drawing Download
- SLM643LSF Technical Drawing Download
- SLM643R Technical Drawing Download
- SLM643RS Technical Drawing Download
- SLM643RSF Technical Drawing Download
To download product materials, please login or register for an account.
