- Robust flexible housing.
- Available with waterproof connectors.
- Long stalk - front only option also available.
- Warranty: 3 Years
- Approvals: ECE R3, R7, R10.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SLM647L | 60° Short Stalk LED Outline Marker Light Front / Rear with Reflector - Left Side | IP68 | 12/24 | 0.03A @ 12V, 0.03A @ 24V | 270 | None | Red/White | Red/Clear | N/A | 0.16 | 131(H) X 130(L) X 37(D) |
| SLM647LS | 60° Short Stalk LED Outline Marker Light Front / Rear with Reflector - Left Side with Superseal Connector | IP68 | 12/24 | 0.03A @ 12V, 0.03A @ 24V | 300 | Superseal | Red/White | Red/Clear | N/A | 0.1865 | 131(H) X 130(L) X 37(D) |
| SLM647R | 60° Short Stalk LED Outline Marker Light Front / Rear with Reflector - Right Side | IP68 | 12/24 | 0.03A @ 12V, 0.03A @ 24V | 270 | None | Red/White | Red/Clear | N/A | 0.16 | 131(H) X 130(L) X 37(D) |
| SLM647RS | 60° Short Stalk LED Outline Marker Light Front / Rear with Reflector - Right Side with Superseal Connector | IP68 | 12/24 | 0.03A @ 12V, 0.03A @ 24V | 300 | Superseal | Red/White | Red/Clear | N/A | 0.1865 | 131(H) X 130(L) X 37(D) |
Download Product Information
- SLM647L Product Spec Sheet Download
- SLM647LS Product Spec Sheet Download
- SLM647R Product Spec Sheet Download
- SLM647RS Product Spec Sheet Download
- SLM647L Technical Drawing Download
- SLM647LS Technical Drawing Download
- SLM647R Technical Drawing Download
- SLM647RS Technical Drawing Download
To download product materials, please login or register for an account.
