- Slimline surface mount design.
- Fully homologated for vertical and horizontal mounting.
- Front and rear marker light options also available.
- Some variants are made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R3, R10, R91.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SM12801 | Slimline, Surface Mount LED Side Marker Light with Retroreflector | IP68 | 12/24 | 0.033A @ 12V, 0.029A @ 24V | 220 | None | Amber | Amber | N/A | 0.055 | 45(H) X 105(L) X 12(D) |
| SM12801DC | Slimline, Surface Mount LED Side Marker Light with Retroreflector with Deutsch Connector | IP68 | 12/24 | 0.033A @ 12V, 0.029A @ 24V | 265 | Deutsch | Amber | Amber | N/A | 0.062 | 45(H) X 105(L) X 12(D) |
| SM12801S | Slimline, Surface Mount LED Side Marker Light with Retroreflector with Superseal Connector | IP68 | 12/24 | 0.033A @ 12V, 0.029A @ 24V | 250 | Superseal | Amber | Amber | N/A | 0.064 | 45(H) X 105(L) X 12(D) |
Download Product Information
- SM12801 Product Spec Sheet Download
- SM12801DC Product Spec Sheet Download
- SM12801S Product Spec Sheet Download
- SM12801 Technical Drawing Download
- SM12801DC Technical Drawing Download
- SM12801S Technical Drawing Download
To download product materials, please login or register for an account.
