- Powder coated cast aluminium housing.
- Power consumption less than 1/4 of a halogen worklamp.
- Stainless steel bracket.
- Compact design.
- Made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R10.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | INTEGRAL SWITCH | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
WLE004S | Compact Round High Power LED Worklamp with Superseal Connector | IP67 | 10-30 | 0.655A @ 12V, 0.326 @ 24V | 1040 | Superseal | White | Clear | N/A | 83 | 0.441 | 122(H) X 65(D) |
WLE004K | Compact Round High Power LED Worklamp with 360° Bearing | IP67 | 10-30 | 0.655A @ 12V, 0.326 @ 24V | 1000 | None | White | Clear | N/A | 83 | 0.433 | 122(H) X 65(D) |
Download Product Information
- WLE004S Product Spec Sheet Download
- WLE004K Product Spec Sheet Download
- WLE004K Technical Drawing Download
To download product materials, please login or register for an account.
